SPECIFICATIONS
Model | FWS-30 | |
Mode | Reciprocating oscillation + thermostatic water bath | |
Function | Operating Temp Range | RT~100°C |
Tem. Resolution Ratio | 0.1°C | |
Tem. Motion | ±1.0°C | |
Tem. Uniformity | ±0.2°C | |
Reciprocal Oscillation Amplitude | 16 or 24mm (Ex-factory is 24mm) | |
Reciprocating Frequency Range | 20~200 (r/min) | |
Reciprocating Frequency Accuracy | ±1rpm | |
Structure | Water Tank | Miror stainless steel |
Outer Shell | Cold rolling stell electrostatic spraying exterior | |
Upper Cover | Mirror stainless steel | |
Insulating Layer | Polyurethane | |
Heater | Stainless Steel Heater | |
Driving Mode | Crankshaft+double link+four wheels | |
Shelf | Mirror stainless steel | |
Power rating | 1.5kW | |
Controller | Tem. Control Mode | LCD PID Intelligent control |
Reciprocating Control Mode | ||
Setting Mode | Touch button setting | |
Tem. Display Mode | LCD Display | |
Speed Display Mode | ||
Timer | 0-9999 min | |
Operation Function | Fixed value operation, timing, auto stop, quickly stop start | |
Temperature Sensor | Pt100 | |
Speed Sensor | Hoare | |
Additional Function | Deviation correction, menu keys locked, power-off memory | |
Safety device | over temperature alarm, menu locked, water full or shortage protection, Motor shaft lock protection; | |
Specification | Water Tank Size (W*L*H)(mm) | 500*310*200 |
Exterior Size (W*L*H)(mm) | 828*360*425 | |
Packing Size (W*L*H)(mm) | 908*440*505 | |
Spring Shock Basket Size (mm) | 395*250 | |
Shock Basket Largest Single Size (ml/piece) | 100ml*12/250*8/500*6 | |
Inside Volume | 31L | |
Shock Basket Bearing | 5kg/layer | |
Current Rating (50Hz) | AC220V/6.8A | |
NW/GW (kg) | 20/30 | |
Accessries | Water bath flask seat, tube rack |
