SPECIFICATIONS
Model | NV222 | NV422 | NV622 |
Capacity (g) | 220 | 420 | 620 |
Readability (g) | 0.01 | ||
Repeatability (std. Dev.) | 0.01 | 0.02 | |
Linearity (g) | 0.02 | ||
Span Calibration Mass | 200 | 300 | |
Linearity Calibration Mass | 100,200 g | 200, 400 g | 300, 600 g |
Stabilization Time (s) | 1 | 1.5 | |
Construction | ABS housing and stainless steel pan | ||
Draftshied | n/a | ||
Calibration | User-selectable external span or linearity calibration / Digital with external weight | ||
Tare Range | Full capacity by subtration | ||
Weighing Units | g, kg, N, oz, ozt, dwt, Ib, Ib:oz, ct, grain, taels (3), Tical, Tola | ||
Application Modes | Weighing, Parts Counting, Percent Weighing, Checkweighing | ||
Power Requirement | AC adapter (included) or 4 C batteries (not included) | ||
Typical Battery Life | 270 hours | ||
Temperature Range | 10°C to 40°C at 10% to 85% relative humidity, non-condensing | ||
Storage Conditions | -20°C to 50 °C at 10% to 90% relative humidity, non-condensing | ||
Communication | RS232, USB, or Ethernet (available as accessories) | ||
Display Type | Liquid Crystal Display (LCD) with backlight | ||
Draftshield Dimensions | n/a | ||
Pan Size (W x D) | 145 mm | ||
Balance Dimensions (W x D x H) | 204 x 230 x 70 mm | ||
Shipping Dimensions (W x D x H) | 300 x 250 x 134 mm | ||
Net Weight | 1.0 kg |
